Motorola MC40 Integrator Guide

MC40IntegratorGuide
values:SupplementalsAuto,SupplementalsSmart,Supplementals378-379,Supplementals978-979,
Supplementals977orSupplementals414-419-434-439(2to20,default10).
•Bookland-Enableordisablethisoption.Acheckinthecheckboxindicatesthattheoptionisenabled.
•Coupon-EnablesCouponcodedecoding.NotethatinordertosuccessfullydecodeCouponcodes,allofthe
correctdecodersmustbeenabled.Acheckinthecheckboxindicatesthattheoptionisenabled.
•ConvertDataBarToUPCEAN-IfthisissetitconvertsDataBarbarcodestoUPC/EANformat.Forthissetting
toworkUPC/EANsymbologiesmustbeenabled.Acheckinthecheckboxindicatesthattheoptionisenabled.
ReaderParams
Allowsthecongurationofparametersspecictotheselectedbarcodereader.
•BeamTimer-Setsthemaximumamountoftimethatthereaderremainson(0-60,000msinincrementsof100
ms).Avalueof0setsthereadertostayonindenitely(default-15000).
•LinearSecurityLevel-Setsthenumberoftimesabarcodeisreadtoconrmanaccuratedecode.
–SecurityShortorCodabar-TwotimesreadredundancyifshortbarcodeorCodabar.
–SecurityAllTwice-Twotimesreadredundancyforallbarcodes(default).
–SecurityLongandShort-Twotimesreadredundancyforlongbarcodes,threetimesforshortbarcodes.
–SecurityAllThrice-Threetimesreadredundancyforallbarcodes.
•Picklist-Allowstheimagertodecodeonlythebarcodethatisdirectlyunderthecross-hair/reticle(+)partofthe
pattern.Thisfeatureisusefulinapplicationswheremultiplebarcodesmayappearintheeldofviewduringa
decodesessionandonlyoneofthemistargetedfordecode.
–Disable–DisablesPicklistmode.Anybarcodewithintheeldofviewcanbedecoded(default).
–Centered-EnablesthePicklistmodesothatonlythebarcodeinthecenteroftheimageisdecoded.This
ismostusefulwhenusedinconjunctionwiththestaticanddynamicreticleviewndermodes.Note:This
modeisonlyvalidfordecodermodulesthatsupportsaviewnder.Ifonetriestosetthisforaunsupported
decoderthenthedevicewouldissueanerror.(Camerascanneronly).
–Reticle-EnablesthePicklistmodesothatonlythebarcodethatisdirectlyunderthecross-hair(reticle)is
decoded.Thisisusefulwhenusedinconjunctionwiththestaticanddynamicreticleviewndermodes.
(ScanModuleOnly)
•LCDMode-EnablesordisablesLCDmode.LCDmodeenhancestheabilityoftheimagertoreadbarcodes
fromLCDdisplayssuchascellphones(imageronly).
–Disable-DisablestheLCDmode(default).
–Enable-EnablesLCDmode.
WhenusingtheLCDmode,adegradationinperformancemaybeobservedandtheaimingcrosshair
mayblinkuntilthebarcodeisdecoded.
•Illuminationmode-Turnscamerailluminationonandoff.Thisoptionisonlyavailablewhencameraisselected
intheBarcodeinputScannerselectionoption.
–On-Illuminationison.
–Off-Illuminationisoff(default).
•Inverse1DMode-Thisparameterallowstheusertoselectdecodingoninverse1Dbarcodes.
–Disable-Disablesdecodingofinverse1Dbarcodes(default).
4-16
MN000112A01-September2013
