Device Configuration 5 - 21
Figure 5-12 Profile Wired 802.1X screen
5. Set the following Wired 802.1x Settings:
6. Select OK to save the changes to the 802.1x configuration. Select Reset to revert to the last saved configuration.
5.2.5 Profile Interface Configuration
System Profile Configuration
A access point profile can support customizable Ethernet port, virtual interface, port channel, radio and PPPoE configurations
unique to each supported access point model.
A profile’s interface configuration process consists of the following:
• Ethernet Port Configuration
• Virtual Interface Configuration
• Port Channel Configuration
• Access Point Radio Configuration
• WAN Backhaul Configuration
• PPPoE Configuration
Additionally, deployment considerations and guidelines for profile interface configurations are available for review prior to
defining a configuration that could significantly impact the performance of the network. For more information, see WAN
Backhaul Deployment Considerations on page 5-62.
Dot1x Authentication
Control
Select this option to globally enable 802.1x authentication for the selected device. This
setting is disabled by default.
Dot1x AAA Policy Use the drop-down menu to select an AAA policy to associate with wired 802.1x traffic. If
a suitable AAA policy does not exist, click the Create icon to create a new policy or the
Edit icon to modify an existing policy.
Dot1x Guest VLAN
Control
Select this option to globally enable 802.1x guest VLANs for the selected device. This
setting is disabled by default.
MAC Authentication
AAA Policy
Use the drop-down menu to select an AAA authentication policy for MAC address
authentication. If a suitable MAC AAA policy does not exist, click the Create icon to create
a new policy or the Edit icon to modify an existing policy.
