5 - 12 WiNG 5.6 Access Point System Reference Guide
9. Select OK when completed to update the network group alias rules. Select Reset to revert the screen back to its last saved
configuration.
5.1.3.3 Network Service Alias
RF Domain Configuration
A network service alias is a set of configurations that consist of protocol and port mappings. Both source and destination ports
are configurable. For each protocol, up to 2 source port ranges and up to 2 destination port ranges can be configured. A
maximum of 4 protocol entries can be configured per network service alias.
Use a service alias to associate more than one IP address to a network interface, providing multiple connections to a network
from a single IP node.
Network Service Alias can be used in the following location to substitute protocols and ports:
• IP Firewall Rules
To edit or delete a service alias configuration:
1. Select Configuration tab from the Web user interface.
2. Select Devices.
3. Select RF Domain.
4. Select the Network Service Alias tab.
Figure 5-7 RF Domain - Network Service Alias screen
5. Select Edit to modify the attributes of an existing policy or Delete to remove obsolete policies from the list of those
available. Select Add to create a new Network Service Alias.
