5 - 224 WiNG 5.6 Access Point System Reference Guide
5.4.5.3 Profile Interface Override Configuration
Device Overrides
An access point requires its Virtual Interface be configured for layer 3 (IP) access or layer 3 service on a VLAN. A virtual interface
defines which IP address is associated with each connected VLAN ID.
An interface configuration can have overrides applied to customize the configuration to a unique deployment objective. For
more information, refer to the following:
• Ethernet Port Override Configuration
• Virtual Interface Override Configuration
• Port Channel Override Configuration
• Radio Override Configuration
• WAN Backhaul Overrides
• PPPoE Configuration
5.4.5.3.1 Ethernet Port Override Configuration
Profile Interface Override Configuration
Use an Ethernet Port override to change (modify) parameters of an access point’s Ethernet Port configuration.
The following ports are available on supported access point models:
• AP6511 - fe1, fe2, fe3, fe4, up1
• AP6521 - GE1/POE (LAN)
• AP6522/AP6522M - GE1/POE (LAN)
• AP6532 - GE1/POE (LAN)
• AP6562 - GE1/POE (LAN)
• AP7131 - GE1/POE (LAN), GE2 (WAN)
• AP7161 - GE1/POE (LAN), GE2 (WAN)
• AP7181 - GE1/POE (LAN), GE2 (WAN)
• AP8122/AP8132/AP8232 - GE1/POE (LAN), GE2 (WAN)
To define an Ethernet port configuration override:
1. Select the Configuration tab from the Web UI.
2. Select Devices from the Configuration tab.
3. Select Device Overrides.
4. Select a target device from the device browser in the lower, left-hand, side of the UI.
5. Select Interface to expand its sub menu options.
6. Select Ethernet Ports.
NOTE: A blue override icon (to the left of a parameter) defines the parameter as having
an override applied. To remove an override, go to the Basic Configuration screen’s
Device Overrides field and select Clear Overrides. This will remove all overrides
from the device.
