Statistics 13 - 69
13.3.7 Wireless LANs
Access Point Statistics
The Wireless LANs screen displays an overview of access point WLAN utilization. This screen displays access point WLAN
assignment, SSIDs, traffic utilization, number of radios the access point is utilizing on the WLAN and transmit and receive
statistics.
To review a selected access point’s WLAN statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select Wireless LANs.
Role Lists the client’s defined role within the access point managed network.
Client Identity Displays the unique identity of the listed client as it appears to its adopting access point.
Vendor Displays the name of the client vendor (manufacturer).
Band Displays the 802.11 radio band on which the listed wireless client operates.
AP Hostname Displays the administrator assigned hostname of the access point to which this access point
is adopted.
Radio MAC Displays the MAC address of the radio which the wireless client is using.
WLAN Displays the name of the WLAN the access point's using with each listed client. Use this
information to determine if the client's WLAN assignment best suits its intended deployment
in respect to the WLAN's QoS objective.
VLAN Displays the VLAN ID each listed client is currently mapped to as a virtual interface for access
point interoperability.
Last Active Displays the time when this wireless client was last seen (or detected) by a device within the
access point managed network.
Disconnect Client Select a specific client MAC address and select the Disconnect Client button to terminate this
client’s connection to its access point.
Refresh Select the Refresh button to update the screen's statistics counters to their latest values.
