Statistics 13 - 77
The Mesh screen describes the following:
13.3.11 Interfaces
Access Point Statistics
The Interface screen provides detailed statistics on each of the interfaces available on the selected access point. Use this
screen to review the statistics for each interface. Interfaces vary amongst supported access point models.
To review access point interface statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select Interfaces.
The General tab displays by default.
Figure 13-48 Access Point- General Interface screen
Interface Statistics support the following:
Client Displays the system assigned name of each member of the mesh network.
Client Radio MAC Displays the MAC address of each client radio in the mesh network.
Portal Mesh points connected to an external network and forward traffic in and out are mesh
portals. Mesh points must find paths to a portal to access the Internet. When multiple
portals exist, the mesh point must select one.
Portal Radio MAC Lists the MAC addresses of those access points serving as mesh portals.
Connect Time Displays the elapsed connection time for each listed client in the mesh network.
Refresh Select the Refresh button to update the screen’s statistics counters to their latest values.
