Statistics 13 - 101
Figure 13-64 Access Point - GRE Tunnels screen
The access point GRE Tunnels screen displays the following:
13.3.20 Dot1x
Access Point Statistics
Dot1x (or 802.1x) is an IEEE standard for network authentication. Devices supporting Dot1x allow the automatic provision and
connection to the wireless network without launching a Web browser at login. When within range of a Dot1x network, a device
automatically connects and authenticates without needing to manually login.
To view the Dot1x statistics:
1. Select the Statistics menu from the Web UI.
GRE State Displays the current operational state of the GRE tunnel.
Peer IP Address Displays the IP address of the peer device on the remote end of the GRE tunnel.
Tunnel Id Displays the session ID of an established GRE tunnel. This ID is only viable while the tunnel is
operational.
Total Packets
Received
Displays the total number of packets received from a peer at the remote end of the GRE tunnel.
Total Packets Sent Displays the total number of packets sent from this access point to a peer at the remote end
of the GRE tunnel.
Total Packets
Dropped
Lists the number of packets dropped from tunneled exchanges between this access point and
a peer at the remote end of the VPN tunnel
Refresh Select the Refresh button to update the screen’s statistics counters to their latest value.
