Statistics 13 - 19
13.The Traffic Statistics statistics table displays the following information for transmitted and received packets:
14.The SMART RF Activity area displays the following:
13.2.2 Inventory
RF Domain Statistics
The Inventory screen displays an inventory of RF Domain member access points, connected wireless clients, wireless LAN
utilization and radio availability.
To display RF Domain inventory statistics:
1. Select the Statistics menu from the Web UI.
2. Select a RF Domain from under the System node on the top, left-hand side, of the screen.
3. Select Inventory from the RF Domain menu.
Total Bytes Displays the total bytes of data transmitted and received within the access point RF
Domain.
Total Packets Lists the total number of data packets transmitted and received within the access point
RF Domain.
User Data Rate Lists the average user data rate within the access point RF Domain.
Bcast/Mcast Packets Displays the total number of broadcast/multicast packets transmitted and received within
the access point RF Domain.
Management Packets This is the total number of management packets processed within the access point RF
Domain.
Tx Dropped Packets Lists total number of dropped data packets within the access point RF Domain.
Rx Errors Displays the number of errors encountered during data transmission within the access
point RF Domain. The higher the error rate, the less reliable the connection or data
transfer.
Time Period Lists the time period when Smart RF calibrations or adjustments were made to
compensate for radio coverage holes or interference.
Power Changes Displays the total number of radio transmit power changes that have been made using
SMART RF within the access point RF Domain.
Channel Changes Displays the total number of radio transmit channel changes that have been made using
SMART RF within the access point RF Domain.
Coverage Changes Displays the total number of radio coverage area changes that have been made using
SMART RF within the access point RF Domain.
