Statistics 13 - 67
13.3.5 AP Detection

Access Point Statistics
The AP Detection screen displays potentially hostile access points, their SSIDs, reporting AP, and so on. Continuously
revalidating the credentials of detected devices reduces the possibility of an access point hacking into the network.
To view the AP detection statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select AP Detection.
Figure 13-40 Access Point - AP Detection
The AP Detection screen displays the following:
Unsanctioned AP Displays the MAC address of a detected access point that is yet to be authorized for
interoperability within the access point managed network.
Reporting AP Displays the hardware encoded MAC address of the radio used by the detecting access point.
Select an access point to display configuration and network address information in greater
detail.
SSID Displays the WLAN SSID the unsanctioned access point was detected on.
AP Mode Displays the operating mode of the unsanctioned access point.
Radio Type Displays the type of the radio on the unsanctioned access point. The radio can be 802.11b,
802.11bg, 802.1bgn, 802.11a or 802.11an.
Channel Displays the channel the unsanctioned access point is currently transmitting on.
