Statistics 13 - 53
13.2.12.2 WIPS Events
WIPS
Refer to the WIPS Events screen to assess WIPS events detected by RF Domain member access point radios and reported to
the controller or service platform.
To view the rogue access point statistics:
1. Select the Statistics menu from the Web UI.
2. Select a RF Domain from under the System node on the top, left-hand side, of the screen.
3. Expand the WIPS menu item and select WIPS Events.
Figure 13-31 RF Domain - WIPS Events screen
The WIPS Events screen displays the following:
Refresh Select the Refresh button to update the statistics counters to their latest values.
Event Name Displays the event name of the intrusion detected by a RF Domain member access point.
Reporting AP Displays the MAC address of the RF Domain member access point reporting the event.
Originating Device Displays the MAC address of the device generating the event.
Detector Radio Displays Access Point radio number detecting the event. AP7131N models can have from
1-3 radios depending on the SKU. AP6532, AP6522, AP6562, AP71xx, AP8132 and AP8232
models have 2 radios, while AP6511 and AP6521 models have 1 radio. An ES6510 is a
controller or service platform managed Ethernet Switch, with no embedded device radios.
Time Reported Displays a time stamp of when the event was reported by the RF Domain member access
point radio.
Clear All Select the Clear All button to clear the statistics counters and begin a new data collection.
Refresh Select the Refresh button to update the statistics counters to their latest values.
