13 - 78 WiNG 5.6 Access Point System Reference Guide
• General Interface Details
• Network Graph
13.3.11.1 General Interface Details
Interfaces
The General tab provides information on a selected access point interface such as its MAC address, type and TX/RX statistics.
The General table displays the following:
The Specification table displays the following information:
Name Displays the name of the access point interface ge1, vlan1 etc.
Interface MAC Address Displays the MAC address of the interface.
IP Address IP address of the interface.
IP Address Type Displays the IP address type, either IPv4 or IPv6.
Secondary IP Displays a list of secondary IP resources assigned to this interface.
Hardware Type Displays the networking technology.
Index Displays the unique numerical identifier for the interface.
Access VLAN Displays the tag assigned to the native VLAN.
Access Setting Displays the VLAN mode as either Access or Trunk.
Administrative Status Displays whether the interface is currently UP or DOWN.
Media Type Displays the physical connection type of the interface.
Medium types include:
Copper - Used on RJ-45 Ethernet ports
Optical - Used on fibre optic gigabit Ethernet ports
Protocol Displays the routing protocol used by the interface.
MTU Displays the maximum transmission unit (MTU) setting configured on the interface. The
MTU value represents the largest packet size that can be sent over a link. 10/100 Ethernet
ports have a maximum setting of 1500.
Mode Lists whether traffic on the listed port is Layer 2 or Layer 3.
Metric Displays the metric associated with the interface’s route.
Maximum Speed Displays the maximum speed the interface uses to transmit or receive data.
Admin Speed Displays the speed the port can transmit or receive. This value can be either 10, 100, 1000
or Auto. This value is the maximum port speed in Mbps. Auto indicates the speed is
negotiated between connected devices.
Operator Speed Displays the current speed of data transmitted and received over the interface.
Admin Duplex Setting Displays the administrator’s duplex setting.
Current Duplex Setting Displays the interface as either half duplex, full duplex or unknown.
