5 - 66 WiNG 5.6 Access Point System Reference Guide
5.2.6.1 DNS Configuration
Profile Network Configuration
Domain Naming System (DNS) is a hierarchical naming system for resources connected to the Internet or a private network.
Primarily, DNS resources translate domain names into IP addresses. If one DNS server does not know how to translate a
particular domain name, it asks another one until the correct IP address is returned. DNS enables access to resources using
human friendly notations. DNS converts human friendly domain names into notations used by different networking equipment
for locating resources.
As a resource is accessed (using human-friendly hostnames), it’s possible to access the resource even if the underlying machine
friendly notation name changes. Without DNS, in the simplest terms, you would need to remember a series of numbers
(123.123.123.123) instead of an easy to remember domain name (www.domainname.com).
To define the DNS configuration:
1. Select the Configuration tab from the Web UI.
2. Select Devices.
3. Select System Profile from the options on left-hand side of the UI.
4. Expand the Network menu and select DNS.
Figure 5-38 Network - DNS screen
5. Provide a default Domain Name used when resolving DNS names. The name cannot exceed 64 characters.
6. Set the following DNS configuration data:
7. In the Name Servers field, provide the IP addresses of up to three DNS server resources available to the access point.
Enable Domain Lookup Select this option to enable DNS. When enabled, human friendly domain names can be
converted into numerical IP destination addresses. This feature is enabled by default.
DNS Server Forwarding Select to enable the forwarding DNS queries to external DNS servers if a DNS query
cannot be processed by the access point’s own DNS resources. This feature is disabled
by default.
