Statistics 13 - 83
The Access Point RTLS screen displays the following for Ekahau tags:
13.3.13 PPPoE
Access Point Statistics
The PPPoE statistics screen displays stats derived from the AP’s access to high-speed data and broadband networks. PPPoE
uses standard encryption, authentication, and compression methods as specified by the PPPoE protocol. PPPoE enables access
points to establish a point-to-point connection to an ISP over existing Ethernet interface.
To review a selected access point’s PPPoE statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its
connected access points.
3. Select PPPoE.
Figure 13-51 Access Point - PPPoE screen
The Configuration Information field screen displays the following:
Tag Reports Displays the number of tag reports received from locationing equipped radio devices
supporting RTLS.
Refresh Select the Refresh button to update the screen’s statistics counters to their latest values.
Shutdown Displays whether a high speed client mode point-to-point connection has been enabled using
the PPPoE protocol.
Service Lists the 128 character maximum PPPoE client service name provided by the service provider.
DSL Modem Network
(VLAN)
Displays the PPPoE VLAN (client local network) connected to the DSL modem. This is the local
network connected to DSL modem.
