Network Configuration 7 - 37
8. Select + Add Row to define String Alias settings:
Use the String Alias field to create aliases for strings that can be utilized at different deployments. For example, if the
main domain at a remote location is called loc1.domain.com and at another deployment location it is called
loc2.domain.com, the alias can be overridden at the remote location to suit the local (but remote) requirement. At one
remote location, the alias functions with the loc1.domain.com domain and at the other with the loc2.domain.com domain.
A string alias can be used to replace domain name strings in DHCP.
9. Select OK when completed to update the basic alias rules. Select Reset to revert the screen back to its last saved
configuration.
7.6.2 Network Group Alias
Alias
A network group alias is a set of configurations that consist of host and network configurations. Network configurations are
complete networks in the form 192.168.10.0/24 or IP address range in the form 192.168.10.10-192.168.10.20. Host
configuration is in the form of single IP address, 192.168.10.23.
A network group alias can contain multiple definitions for host, network, and IP address range. A maximum of eight (8) host
entries, eight (8) network entries and eight (8) IP addresses range entries can be configured inside a network group alias. A
maximum of 32 network group alias entries can be created.
A network group alias is used in IP firewall rules to substitute hosts, subnets and IP address ranges:
To edit or delete a network alias configuration:
1. Select Configuration tab from the user interface.
2. Select Network.
3. Select the Alias item. The Basic Alias screen displays.
4. Select the Network Group Alias tab.
Name If adding a new String Alias, provide it a distinguishing name up to 32 characters. The alias
name always starts with a dollar sign ($).
Value Provide a string value to use in the alias.
