6 - 40 WiNG 5.6 Access Point System Reference Guide
6.1.8 Configuring Advanced WLAN Settings
Wireless LANs
To configure advanced RADIUS configuration and radio rate settings for a WLAN:
1. Select the Configuration tab from the Web UI.
2. Select Wireless.
3. Select Wireless LANs to display a high level display of existing WLANs.
4. Select the Add button to create an additional WLAN, or Edit to modify the properties of an existing WLAN.
5. Select Advanced.
Figure 6-18 WLAN - Advanced Configuration screen
6. Refer to the Advanced RADIUS Configuration field to set the WLAN’s NAS configuration and RADIUS Dynamic
Authorization.
7. Refer to the Radio Rates field to define selected data rates for both the 2.4 GHz and 5.0 GHz bands.
NAS Identifier Specify what is included in the RADIUS NAS-Identifier field for authentication and
accounting packets. This is an optional setting, and defaults are used if no values are
provided.
NAS Port The profile database on the RADIUS server consists of user profiles for each connected
network access server (NAS) port. Each profile is matched to a user name representing a
physical port. When the access point authorizes users, it queries the user profile database
using a user name representative of the physical NAS port making the connection.
RADIUS Dynamic
Authorization
Select this radio button to enable the RADIUS protocol to support unsolicited messages
sent from the RADIUS server. These messages allow administrators to issue change of
authorization (CoA) messages, which affect session authorization, or Disconnect Message
(DM), which cause a session to terminate immediately. This feature is disabled by default.
