Device Configuration 5 - 47
20. Select + Add Row as needed to include additional indexes.
21. Refer to the Spanning Tree Port Priority table.
Define an Instance Index using the spinner control and then set the Priority. The lower the priority, a greater likelihood
of the port becoming a designated port.
22. Select + Add Row needed to include additional indexes.
23. Select OK to save the changes made to the Ethernet Port Spanning Tree configuration. Select Reset to revert to the last
saved configuration.
<=10000000 bits/sec 2000000
<=100000000 bits/sec 200000
<=1000000000 bits/sec 20000
<=10000000000 bits/sec 2000
<=100000000000 bits/sec 200
<=1000000000000 bits/sec 20
>1000000000000 bits/sec 2
