Device Configuration 5 - 75
17. Refer to the Peer table to review the configurations of the peers available for tunnel connection.
Select + Add Row to populate the table with a maximum of two peer configurations.
Figure 5-44 Network - L2TPv3 screen - Add L2TPv3 Peer Configuration
18. Define the following Peer parameters:
19. Select OK to save the peer configuration.
20. Select OK to save the changes within the L2TPv3 Tunnel screen. Select Reset to revert the screen to its last saved
configuration.
Video Set the random early detection threshold in % for video traffic. Set a value from 1 - 100%.
The default is 25%.
Voice Set the random early detection threshold in % for voice traffic. Set a value from 1 - 100%.
The default is 25%.
Peer ID Define the primary peer ID used to set the primary and secondary peer for tunnel failover.
If the peer is not specified, tunnel establishment does not occur. However, if a peer tries
to establish a tunnel with this access point, it creates the tunnel if the hostname and/or
Router ID matches.
Peer IP Address Select this option to enter the numeric IP address used as the tunnel destination peer
address for tunnel establishment.
Host Name Assign the peer a hostname that can be used as matching criteria in the tunnel
establishment process.
Router ID Specify the router ID sent in tunnel establishment messages with this specific peer.
Encapsulation Select either IP or UDP as the peer encapsulation protocol. The default setting is IP. UDP
uses a simple transmission model without implicit handshakes.
UDP Port If UDP encapsulation is selected, use the spinner control to define the UDP encapsulation
port.
IPSEC Secure Select this option to provide IPSEC security for the tunnel.
IPSEC Gateway Enter the IP address/Hostname for the IPSEC gateway.
