5 - 78 WiNG 5.6 Access Point System Reference Guide
25. Select the + Add Row button to set the following:
26. Select OK to save the changes to the session configuration. Select Reset to revert to the last saved configuration.
UDP Port If UDP encapsulation is selected, use the spinner control to define the UDP encapsulation
port. This is the port where the L2TP service is running.
Source VLAN Define the VLAN range (1 - 4,094) to include in the tunnel. Tunnel session data includes
VLAN tagged frames.
Native VLAN Select this option to define the native VLAN that will not be tagged.
Cookie Size Set the size of the cookie field within each L2TP data packet. Options include 0, 4 and 8.
The default setting is 0.
Value 1 Set the cookie value first word.
Value 2 Set the cookie value second word.
End Point Define whether the tunnel end point is local or remote.
