Motorola WiNG 5.6 - Page 175

Device Configuration 5 - 89
5. Select IP Routing to enable static routes using IPv4 addresses. This option is enabled by default.
6. Select the Policy Based Routing policy to apply to this profile. Select the Create icon to create a policy based route or
select the Edit icon to edit an existing policy after selecting it in the drop-down list.
7. Select Add Row + as needed to include single rows with in the static IPv4 route table.
8. Add IP addresses and network masks in the Network Address column of the Static Routes table.
9. Provide the Gateway used to route traffic.
10. Refer to the Default Route Priority field and set the following parameters:
11. Select the IPv6 Routing tab. IPv6 networks are connected by IPv6 routers. IPv6 routers pass IPv6 packets from one network
segment to another.
Figure 5-52 Static Routes screen, IPv6 Routing tab
Static Default Route
Priority
Use the spinner control to set the priority value (1 - 8,000) for the default static route.
This is weight assigned to this route versus others that have been defined. The default
setting is 100.
DHCP Client Default Route
Priority
Use the spinner control to set the priority value (1 - 8,000) for the default route learnt
from the DHCP client. The default setting is 1000.
Enable Routing Failure When selected, all default gateways are monitored for activity. The system will failover
to a live gateway if the current gateway becomes unusable. This feature is enabled by
default.
