5 - 92 WiNG 5.6 Access Point System Reference Guide
Figure 5-54 Network - OSPF Settings tab
5. Enable/disable OSPF and provide the following dynamic routing settings:
Enable OSPF Select this option to enable OSPF for this access point. OSPF is disabled by default.
Router ID Select this option to define a router ID (numeric IP address) for this access point. This
ID must be established in every OSPF instance. If not explicitly configured, the highest
logical IP address is duplicated as the router identifier. However, since the router
identifier is not an IP address, it does not have to be a part of any routable subnet in the
network.
Auto-Cost Select this option to specify the reference bandwidth (in Mbps) used to calculate the
OSPF interface cost if OSPF is either STUB or NSSA. The default setting is 1.
Passive Mode on All
Interfaces
When selected, all layer 3 interfaces are set as an OSPF passive interface. This setting
is disabled by default.
Passive Removed If enabling Passive Mode on All Interfaces, use the spinner control to select VLANs (by
numeric ID) as OSPF non passive interfaces. Multiple VLANs can be added to the list.
Passive Mode If disabling Passive Mode on All Interfaces, use the spinner control to select VLANs (by
numeric ID) as OSPF passive interfaces. Multiple VLANs can be added to the list.
