5 - 94 WiNG 5.6 Access Point System Reference Guide
Figure 5-55 Network - Area Settings tab
12. Review existing Area Settings configurations using:
13. Select Add to create a new OSPF configuration, Edit to modify an existing configuration or Delete to remove a
configuration.
Figure 5-56 Network - OSPF Area Configuration screen
Area ID Displays either the IP address or integer representing the OSPF area.
Authentication Type Lists the authentication schemes used to validate the credentials of dynamic route
connections.
Type Lists the OSPF area type in each listed configuration.
