5 - 100 WiNG 5.6 Access Point System Reference Guide
34. Enable the Enforce Duplicate Address option to enforce duplicate address protection when any wired port is connected
and in a forwarding state. This option is enabled by default.
35. Refer to the IPv6 Address Prefix from Provider table to create IPv6 format prefix shortcuts as supplied by an ISP.
Select + Add Row to launch a sub screen wherein a new delegated prefix name and host ID can be defined.
Figure 5-61 Network - OSPF Virtual Interfaces - Basic Configuration screen - IPv6 tab - Add Address Prefix from Provider
36. Select OK to save the changes to the new IPv6 prefix from provider. Select Exit to close the screen without saving the
updates.
37. Refer to the IPv6 Address Prefix from Provider EUI64 table to set an (abbreviated) IP address prefix in EUI64 format.
Select + Add Row to launch a sub screen wherein a new delegated prefix name and host ID can be defined in EUI64 format.
IPv6 Address Static
using EUI64
Optionally set up to 15 global IPv6 IP addresses (in the EUI-64 format) that can created
statically. The IPv6 EUI-64 format address is obtained through a 48-bit MAC address. The
MAC is initially separated into two 24-bits, with one being an OUI (Organizationally Unique
Identifier) and the other being client specific. A 16-bit 0xFFFE is then inserted between the
two 24-bits for the 64-bit EUI address. IEEE has chosen FFFE as a reserved value which can
only appear in EUI-64 generated from the an EUI-48 MAC address.
IPv6 Address Link
Local
Provide the IPv6 local link address. IPv6 requires a link local address assigned to every
interface the IPv6 protocol is enabled, even when one or more routable addresses are
assigned.
Delegated Prefix
Name
Enter a 32 character maximum name for the IPv6 address prefix from provider.
Host ID Define the subnet ID, host ID and prefix length.
