Device Configuration 5 - 123
Figure 5-77 Network - Alias - Network Group Alias Add screen
7. If adding a new Network Group Alias, provide it a name of up to 32 characters.
8. Define the following network group alias parameters:
9. Within the Range table, use the + Add Row button to specify the Start IP address and End IP address for the alias range
or double-click on an existing an alias range entry to edit it.
10. Select OK when completed to update the network group alias rules. Select Reset to revert the screen back to its last saved
configuration.
NOTE: The Network Group Alias Name always starts with a dollar sign ($).
Host Specify the Host IP address for up to eight IP addresses supporting network aliasing. Select the
down arrow to add the IP address to the table.
Network Specify the netmask for up to eight IP addresses supporting network aliasing. Subnets can
improve network security and performance by organizing hosts into logical groups. Applying the
subnet mask to an IP address separates the address into a host address and an extended
network address. Select the down arrow to add the mask to the table.
