5 - 134 WiNG 5.6 Access Point System Reference Guide
Figure 5-85 Profile Security - VPN Transform Set create/modify screen
18. Define the following settings for the new or modified Transform Set configuration:
19. Select OK to save the changes made within the Transform Set screen. Select Reset to revert to the last saved
configuration.
20. Select the Crypto Map tab.
Use crypto maps (as applied to IPSec VPN) to combine the elements used to create IPSec SAs (including transform sets).
Transform Set If creating a new transform set, define a 32 character maximum name to differentiate
this configuration from others with similar attributes.
Authentication Algorithm Set the transform sets’s authentication scheme used to validate identity credentials.
Use the drop-down menu to select either HMAC-SHA or HMAC-MD5. The default
setting is HMAC-SHA.
Encryption Algorithm Set the transform set encryption method for protecting transmitted traffic. Options
include DES, 3DES, AES, AES-192 and AES-256. The default setting is AES-256.
Mode Use the drop-down menu to select either Tunnel or Transport as the IPSec tunnel type
used with the transform set. Tunnel is used for site-to-site VPN and Transport should be
used for remote VPN deployments.
