Device Configuration 5 - 193
5. Set the following Light Sensor settings for the AP8132’s sensor module:
6. Enable or disable the following Environmental Sensors:
7. Define or override the following Shared Configuration setting:
8. Select OK to save the changes made to the environmental sensor screen. Select Reset to revert to the last saved
configuration.
Enable Light Sensor Select this option to enable the light sensor on the module. This setting is enabled by
default. The light sensor reports whether the access point has its light sensor powered on
or off.
Polling Time to
Determine if Light is On/
Off
Define an interval in Seconds (2 - 201) or Minutes (1 - 4) for the sensor module to poll its
environment to assess light intensity to determine whether lighting is on or off. The
default polling interval is 10 seconds. Light intensity is used to determine whether the
access point’s deployment location is currently populated with clients.
Shutdown WLAN Radio
at Low Limit of Light
Threshold
Select this option to power off the AP8132’s radios if the light intensity falls below the set
threshold. If enabled, select All (both AP8132 radios), radio-1 or radio-2.
Low Limit of Light
Threshold
Set the low threshold limit (from 0 - 1,000 lux) to determine whether the lighting is off in
the AP8132’s deployment location. The default is 100.
High Limit of Light
Threshold
Set the upper threshold limit (from 100 - 10,000 lux) to determine whether the lighting is
on in the AP8132’s deployment location. The default is 500.
Enable Temperature
Sensor
Select this option to enable the module’s temperature sensor. Results are reported back
to the access point’s Environment screens within the Statistics node. This setting is
enabled by default.
Enable Motion Sensor Select this option to enable the module’s motion sensor. Results are reported back to the
access point’s Environment screens within the Statistics node. This setting is enabled by
default.
Enable Humidity Sensor Select this option to enable the module’s humidity sensor. Results are reported back to the
access point’s Environment screens within the Statistics node. This setting is enabled by
default.
Polling Interval for All
Sensors
Set an interval in either Seconds (1 - 100) or Minutes (1 - 2) for the time between all
environmental polling (both light and environment). The default setting is 5 seconds.
