Device Configuration 5 - 217
Figure 5-143 Device Overrides - General screen
7. Select + Add Row below the Network Time Protocol (NTP) table to define (or override) the configurations of NTP server
resources used it obtain system time. Set the following parameters to define the NTP configuration:
8. Refer to the RF Domain Manager field to configure this device as a RF Domain manager.
9. Select the Capable option to enable or disable this device as a RF Domain manager.
10. Select the Priority option to enable configuring a priority value for this device when election to become a Domain Manager
is conducted. Set a value using the spinner control. Setting a low value increases the chance of this device becoming the
RF Domain manager.
11. Select OK to save the changes and overrides made to the general profile configuration. Select Reset to revert to the last
saved configuration.
NOTE: A blue override icon (to the left of a parameter) defines the parameter as having
an override applied. To remove an override, go to the Basic Configuration screen’s
Device Overrides field and select Clear Overrides. This will remove all overrides
from the device.
AutoKey Select this option to enable an autokey configuration for the NTP resource. This is a key
randomly generated for use between the access point and its NTP resource. The default
setting is disabled.
Key If an autokey is not being utilized, you must manually enter a 64 character maximum key
shared for interoperation.
Prefer Select this option to designate this particular NTP resource as preferred. If designating
multiple NTP resources, preferred resources will be given first opportunity to connect to
and provide NTP calibration.
Server IP Set the IP address of each server added as a potential NTP resource.
Version Use the spinner control to specify the version number used by this NTP server resource.
The default setting is 0.
