Device Configuration 5 - 315
information about the interfaces the access point uses. CDP runs only over the data link layer enabling two systems that support
different network-layer protocols to learn about each other.
To override a profile’s CDP configuration:
1. Select Devices from the Configuration tab.
2. Select Device Overrides from the Device menu to expand it into sub menu options.
3. Select a target device from the device browser in the lower, left-hand, side of the UI.
4. Select Network to expand its sub menu options.
5. Select Cisco Discovery Protocol.
Figure 5-206 Cisco Discovery Protocol (CDP) screen
6. Enable/disable CDP and set the following timer settings:
7. Select the OK button located at the bottom right of the screen to save the changes and overrides to the CDP configuration.
Select Reset to revert to the last saved configuration.
5.4.5.4.13Overriding a Link Layer Discovery Protocol Configuration
Overriding the Network Configuration
The Link Layer Discovery Protocol (LLDP) provides a standard way for a controller or access point to advertise information about
themselves to networked neighbors and store information they discover from their peers.
Enable CDP Select this option to enable CDP and allow for network address discovery of Cisco
supported devices and operating system version. This setting is enabled by default.
Hold Time Set a hold time (in seconds) for the transmission of CDP packets. Set a value from 10 -
1,800. The default setting is 180.
Timer Use the spinner control to set the interval for CDP packet transmissions. The default
setting is 60 seconds.
