Device Configuration 5 - 329
Figure 5-216 VPN Step-By-Step Wizard - Step 1
3. Define the following:
4. Click the Next button to go to Step 2.
Tunnel Name Provide a name for the tunnel in the Tunnel Name field.
Tunnel Type Select the tunnel type being created. Two types of tunnels can be created. Site to Site is used
to create a tunnel between two remote sites as indicated in the image. Remote Access is used
to create a tunnel between an user device and a network as indicated in the image.
Interface Select the interface to use. Interface can be a Virtual LAN (VLAN) or WWAN or PPPoE
depending on the interfaces available on the device.
Traffic Selector (ACL) This field creates the Access Control List (ACL) that is used to control who uses the network.
Provide the Source and Destination IP address ranges with their net mask. Click the Add Rule
button to add the rule into the ACL.
