Device Configuration 5 - 345
Figure 5-231 Profile Security - Dynamic NAT screen
7. Select the ACL whose IP rules are applied to this policy based forwarding rule. A new ACL can be defined by selecting the
Create icon, or an existing set of IP ACL rules can be modified by selecting the Edit icon.
8. Use the spinner to select the ACL Precedence. The lower the precedence value, the higher the priority assigned to this
Dynamic NAT policy rule.
9. Use the IP Address Range table to configure IP addresses and address ranges that can used to access the Internet.
10. Select + Add Row to set the IP address range settings for the Bridge NAT configuration.
Interface Lists the outgoing layer 3 interface on which traffic is re-directed. The interface can be an
access point WWAN or PPPoE interface. Traffic can also be redirected to a designated
VLAN.
NAT Pool Displays the NAT pool used by this Bridge NAT entry. A value is only displayed only when
Overload Type has been set to NAT Pool.
Overload IP Lists whether the single global address supporting numerous local addresses.
Overload Type Displays the override type for this policy based forwarding rule.
