5 - 350 WiNG 5.6 Access Point System Reference Guide
Figure 5-235 Device Overrides - VRRP screen
8. If creating a new VRRP configuration, assign a Virtual Router ID from 1 - 255. In addition to functioning as numerical
identifier, the ID identifies the access point’s virtual router a packet is reporting status for.
9. Define the following VRRP General parameters:
Description In addition to an ID assignment, a virtual router configuration can be assigned a textual
description (up to 64 characters) to further distinguish it from others with a similar
configuration.
Priority Use the spinner control to set a VRRP priority setting from 1 - 254. The access point uses
the defined setting as criteria in selection of a virtual router master. The higher the value,
the greater the likelihood of this virtual router ID being selected as the master.
