5 - 376 WiNG 5.6 Access Point System Reference Guide
Figure 5-253 Device Overrides - Advanced Profile MINT screen - Add VLAN screen
29. Set the following VLAN parameters to complete the MINT configuration:
30. Select OK to save the updates and overrides to the MINT Protocol configuration. Select Reset to revert to the last saved
configuration.
31. Select the Advanced Miscellaneous menu item.
VLAN Define a VLAN ID from 1 - 4,094 used by peer controllers for interoperation when
supporting the MINT protocol.
Routing Level Use the spinner control to define or override a routing level of either 1 or 2.
Link Cost Use the spinner control to define or override a link cost from 1 - 10,000. The default
value is 10.
Hello Packet Interval Set or override an interval in either Seconds (1 - 120) or Minutes (1 - 2) for the
transmission of hello packets. The default interval is 4 seconds.
Adjacency Hold Time Set or override a hold time interval in either Seconds (2 - 600) or Minutes (1 - 10) for
the transmission of hello packets. The default interval is 13 seconds.
