Wireless Configuration 6 - 55
Figure 6-24 WLAN - WLAN QoS Policy screen - Rate Limit tab
6. Configure the following intended Upstream Rate Limit parameters for the selected WLAN:
Enable Select this radio button to enable rate limiting for data transmitted from access point
radios to associated clients on this WLAN. Enabling this option does not invoke rate
limiting for data traffic in the downstream direction. This feature is disabled by default.
Rate Define an upstream rate limit from 50 - 1,000,000 kbps. This limit constitutes a threshold
for the maximum number of packets transmitted or received over the WLAN (from all
access categories). Traffic exceeding the defined rate is dropped and a log message is
generated. The default setting is 5000 kbps.
