6 - 74 WiNG 5.6 Access Point System Reference Guide
Figure 6-31 Association ACL screen
5. Select the + Add Row button to add an association ACL template.
6. If creating a new Association ACL, provide a name specific to its function. Avoid naming it after a WLAN it may support.
The name cannot exceed 32 characters.
7. Set the following parameters for the creation or modification of the Association ACL:
8. Select the + Add Row radio button to add MAC address ranges and allow/deny designations.
9. Select OK to update the Association ACL settings. Select Reset to revert to the last saved configuration.
Precedence The rules within a WLAN's ACL are applied to packets based on their precedence values.
Every rule has a unique sequential precedence value you define. You cannot add two
rules’s with the same precedence value. The default precedence is 1, so be careful to
prioritize ACLs accordingly as they are added.
Starting MAC Address Provide a starting client MAC address for non unicast and multicast packet transmissions.
Ending MAC Address Provide an ending MAC address for non unicast and multicast packet transmissions.
Allow/Deny Use the drop-down menu to either Allow or Deny access if a MAC address matches this
rule.
