Network Configuration 7 - 17
Figure 7-10 AAA Policy - RADIUS Authentication tab
6. Refer to the following configured RADIUS Authentication details:
Server Id Displays the numerical server index (1-6) for the accounting server when added to the list
available to the access point.
Host Displays the IP address or hostname of the RADIUS authentication server.
Port Displays the port on which the RADIUS server listens to traffic within the access point
managed network. The port range is 1 - 65,535. The default port is 1812.
Server Type Displays the type of AAA server in use as either Host, onboard-self or onboard-controller.
Request Proxy Mode Displays whether a request is transmitted directly through the server or proxied through
the Virtual Controller AP or RF Domain manager.
Request Attempts Displays the number of attempts a client can retransmit a missed frame to the RADIUS
server before it times out of the authentication session. The available range is from 1 - 10.
The default is 3.
Request Timeout Displays the time from 1 - 60 seconds for the access point’s re-transmission of request
packets. The default is 3 seconds. If this time is exceeded, the authentication session is
terminated.
DSCP Displays the DSCP value as a 6-bit parameter in the header of every IP packet used for
packet classification. The valid range is from 0 - 63, with a default value of 46.
