8 - 18 WiNG 5.6 Access Point System Reference Guide
7. IP firewall rule configurations can either be modified as a collective group of variables or selected and updated individually
as their filtering attributes require a more refined update.
a. Select the Edit Rule icon to the left of a particular IP firewall rule configuration to update its parameters collectively.
Figure 8-7 WLAN Security - IP Firewall Rules - Edit Rule screen
b. Click the icon within the Description column (top right-hand side of the screen) and select IP filter values as needed
to add criteria into the configuration of the IPv4 or IPv6 ACL.
Figure 8-8 WLAN Security - IP Firewall Rules - IP Firewall Rules Add Criteria screen
Define the following parameters for the IP Firewall Rule:
NOTE: Only those selected IP ACL filter attributes display. Each value can have its
current settings adjusted by selecting that IP ACL’s column to display a pop-up to adjust
that one value.
Precedence Specify or modify a precedence for this IP policy between 1-1500. Rules with lower
precedence are always applied to packets first. If modifying a precedence to apply a
higher integer, it will move down the table to reflect its lower priority.
