12 - 22 WiNG 5.6 Access Point System Reference Guide
Figure 12-34 Device Browser - Options for a device - Troubleshooting sub-menu
4. Select Debug Wireless Clients.
Figure 12-35 Device Browser - Options for Devices - Troubleshooting menu - Debug Wireless Clients screen
5. Use the Send Data To drop-down to select the destination for the debug events. Select from Screen or File.
When File is selected, the captured debug events are stored on a file and then saved to a remote location using either the
FTP or TFTP protocols. Use the screen to provide the appropriate information to save the file on the remote server.
6. When in the RF Domain context, use the Edit Devices List to select the device to view the debug information for.
7. Refer to the following Select Debug Messages fields to configure the debug messages that are displayed.
All Debug Messages Select this to display all debug messages generated by the device.
