13 - 138 WiNG 5.6 Access Point System Reference Guide
Figure 13-93 Access Point - Load Balancing screen
The Load Balancing screen displays the following:
Load Balancing Select any of the options to display any or all of the following information in the graph below:
AP Load, 2.4GHz Load, 5GHz Load, and Channel. The graph section displays the load
percentages for each of the selected variables over a period of time, which can be altered
using the slider below the upper graph.
Client Requests
Events
The Client Request Events displays the Time, Client, Capability, State, WLAN and Requested
Channels for all client request events on the access point. Remember,
AP6532 and AP71xx
models can support up to 256 clients per access point and
AP6511 and AP6521 models support
up to 128 clients per access point.
