Spitfire – Maintenance Manual
150
AP-74096, Rev. 1.0, 09/06/05
* Sensor *
LeverUp On Lever up sensor
LeverDown On Lever down sensor
(4/9)
* Sensor *
FootLever On Foot lever SW sensor
PaperEdgeAD 04e P_EDGE sensor
(5/9)
* Sensor *
PaperRear R Off P_REAR_R sensor
PaperRear L Off P_REAR_L sensor
(6/9)
* Sensor *
Headslide On HD_SLIDE sensor
Temp 25°C Head thermistor
(7/9)
* Sensor *
Ink ID 12 34 5678 Ink ID Sensors
SSwwSSSS
(8/9)
* Sensor *
Ink Not Ink NOT sensor
Ink End Ink END sensor
(9/9)
5.4.5. Encoder Menu
This menu displays the detected values from the following encoders.
¾ CR_ENC (Carriage)
¾ PF_ENC (Media feed)
Notes :
¾ For the encoder-detected values, the encoder pulse numbers are displayed in
hexadecimal number.
* Encoder *
CR 0000 CR_ENC
PF 0000 PF_ENC
