8.3. PERIODICAL SERVICES
This section describes the periodical services required for this machine.
The periodical services ensure stable printout quality of the machine.
In the periodical services, some service parts may be checked, cleaned or replaced.
Caution :
¾ There are to parts of periodical service, namely the parts that can be replaced by
the end-user and the parts that needs to be done by authorized Mutoh technicians.
8.3.1. Service by end-user
Perform periodical inspections according to the table below.
Month Mainten.
Cycle
1 2 3 4 5 6 7 8 9 10 11 12
1
x x x x x X X X X X
2
X X
3
x x x x x X X X X X X X
4
x x x x x X X X X X X X
5
daily daily daily daily daily daily daily daily daily daily daily daily
6
daily daily daily daily daily daily daily daily daily daily daily daily
7
daily daily daily daily daily daily daily daily daily daily daily daily
8
weekly weekly weekly weekly weekly weekly weekly weekly weekly weekly weekly weekly
9
weekly weekly weekly weekly weekly weekly weekly weekly weekly weekly weekly weekly
N° Part number Quantity Action
1
DE-11629+ME-80771+AP-51600 1+4+1 CHANGE WIPER ARM+WIPERS+SPONGE
2
MY-35381+ME-80771 1+4 CHANGE WIPER ARM ASSY + WIPERS + SPONGE
3
MY-80165
1
CHANGE UPPER SPONGE AT BACK OF CAPPING
STATION
4
KY-42889 1 Replacing the sponge in the spitting box.
5
KY-80228 (PJ-GLOV + B1-CON-PN-
44)
as required Clean wipers (use gloves and polyknit wipers)
6
KY-80228 (PP-10020 +
T17S250CLN)
as required Flush caps in main station (use pipet and solvent cleaning)
7
KY-80228 (PP-10020 +
T17S250CLN)
as required
Clean edges of the CAPS in main station (uses gloves and
polyknit wipers)
8
KY-80228 (PJ-GLOV + B1-CON-PN-
44)
as required
Clean area around the caps (uses gloves and polyknit
wipers)
9
KY-80228 (PJ-GLOV + PP-10001) as required
Clean around bottom of heads (not nozzle plate)
