Spitfire – Maintenance Manual
170
AP-74096, Rev. 1.0, 09/06/05
Step 4 : Input the measurement as the parameter of the P_REAR sensor position.
* Rear Sensor *
Set Cutting Paper
↓ Set media
* Rear Sensor *
Paper Initial If media is not set
↓ End media initialization
* Rear Sensor *
Paper Width 297.0 mm Check media width
↓ ENTER
* Rear Sensor *
Rear Sensor 7.0 – 27.0 +
17.0 mm -
5.5.10. Test print menu
In this menu, you can print out adjustment patterns for checking various adjustment items.
Make adjustments following the steps below.
Step 1 : Set media as necessary.
Step 2 : After media has been set, the machine prints out the following test Printings.
¾ Nozzle check: Head nozzle check pattern
¾ Adjustment variables: Set values of various adjustment variables
Step 3 : Perform selected test print.
*Print*
NOZZLE CheckAdj.Vari.
