Spitfire – Maintenance Manual
201
AP-74096, Rev. 1.0, 09/06/05
5.11.6. Test Aging Menu
Display:
* TestHeaterAging *
# 20 12mins ON+FAN
A:45 B1:60 B2:60
C:50 D1:40 D2:40
Line2 explanation:
# 20 : Indicates the index number of the current cycle.
When going to the next cycle, this number is increased with 1.
This number will also be displayed when an error occurs, so you know the moment when the error
occurred.
12mins : minutes remaining in the current cycle
ON+FAN: ON means heating, OFF means cooling down, FAN means fans on.
Cycles:
Heating to max temps with fans on: 20min #0,4,8,12,16,…
Cooling down with fans on: 10min #1,5,9,13,17,…
Heating to max temps with fans off: 20min #2,6,10,14,18,…
Cooling down with fans off: 10min #3,7,11,15,19,…
5.11.7. Heater Version Menu
This menu displays the version of the control heater board.
* Version *
Ver = 2.03
