Spitfire – Maintenance Manual
246
AP-74096, Rev. 1.0, 09/06/05
7.16.5. Checklist
Product information :
Serial Number : ________________________________________________
Firmware Version : ________________________________________________
Firmware Version Heater Control Board : ________________________________________________
Basic diagnostics :
Grid power 110V 220V
Grid frequency 50Hz 60Hz
Fuse 1 OK NOK (OPEN)
Power Supply :
LED (Green)
ON :  OFF :  Flashes : 
Control Board :
LEDS : ON OFF Flashes
LED D8
  
LED D1
  
LED D2
  
LED D5
  
LED D7
  
LED D3
  
LED D6
  
Filters OK Bad (visual)
SMD L11
 
SMD L2
 
SMD L6
 
SMD L8
 
Power Board :
D2 Red/Green (revC) Power
ON :  OFF : 
D1 110V/220V
ON :  OFF : 
D23, 21,19,13,6,4 Heater On Flashes?
Cold Start up : _______________________________________________
Operation : _______________________________________________
Heater elements :
Resistance (Ω) 65” 90”
A
2 x 32,3 2 x 24,2
B1/B2
2 x 65,5 2 x 44
C
2 x 32,3 2 x 22,5
D1/ D2
2 x 22,5 2 x 22,5
Thermal Sensor
10k 10k
