7. ADJUSTMENTS
7.1. INTRODUCTION
Adjustments and adjustment procedures required when replacing parts are explained in this chapter.
Notes :
¾ Refer to “Jig and tool list ".
7.2. ADJUSTMENT
The adjustments required when replacing parts are explained below.
When adjusting or replacing maintenance parts shown in the table below, a printing adjustment is required
using the auto-diagnostic function on the printer. Refer to the table below while making adjustments.
Replaced or
adjusted part
Adjustment
order
Adjustment Refer to
1 Head rank input (including initial filling)
→ Head rank input menu
2 Head nozzle check
→ Head Nozzle Check
Menu
3 Head angle check
→ Head Slant Check
Menu
4 Head precision adjustment
→ Head precision
adjustment
5 Repeatability adjustment
→ Repeatability
Adjustment Menu
6 CW adjustment
→ CW Adjustment Menu
7 Test Print
→ Test print menu
Print head
8 Head unit lifespan count reset
→ Parameter
Initialization Menu
1 Parameter backup
→ Parameter backup
2 Firmware installation
→ Firmware installation
3 Machine size select
→ Machine size select
menu
4 Backup parameter installation
→ Backup parameter
installation procedure
5 Media sensor sensitivity adjustment
→ Media sensor
sensitivity adjustment
6 Head rank input
→ Head rank input menu
7 Head nozzle check
→ Head Nozzle Check
Menu
8 Head angle check
→ Head Slant Check
Menu
9 Repeatability adjustment
→ Repeatability
Adjustment Menu
Mainboard
assembly
10 CW adjustment
→ CW Adjustment Menu
