Spitfire – Maintenance Manual
37
AP-74096, Rev. 1.0, 09/06/05
3.4. INSTALLATION
Product installation is explained below.
3.4.1. Choosing a place for the printer
Install the unit on a proper location referring to the following.
Important :
• Do not place the printer on a location under the following conditions. Doing so
may cause the product to fall, become damaged, or cause injury.
o Unstable surfaces
o Slanted surfaces
o Locations that are subject to vibration from other product
• Do not stand on the printer or place any heavy objects on it. Doing so may
cause it to fall over, become damaged, or cause injury.
• Do not cover the ventilation hole of the printer with cloth, such as a blanket or
table cloth. Doing so could prevent the printer from ventilating and cause fire.
• Keep the printer away from humid and dusty areas. Humidity may result in
electrical shock or fire.
3.4.1.1.
Installation environment Requirements
Choose a place for printer installation following the requirements in the table below.
65” model 12.7m² (144ft²) or larger. Frontage of 4.7m (15.7ft) or greater. Area
90” model 14.3m² (162ft²) or larger. Frontage of 5.3m (17.7ft) or greater.
Floor loading capability 2490Pa (300kg/m²) or over
65” 90”
Voltage AC 100-120V
AC 220-240V
AC 100-120V
AC 220-240V
Frequency 60/50Hz±1Hz 60/50Hz±1Hz
Electrical
Capacity AC100V-120V : 12A
AC220V-240V : 6A
AC100V-120V : 13A
AC220V-240V : 7A
In order to protect the printer for over currents, short circuits and earth faults, the building
installation should be equipped with an automatic breaker double pole of 20 A and an earth leakage
switch of 300 mA.
Recommended
working
environment
Temperature: 23°C
Humidity: 55%, without condensation
Operational
conditions
Temperature: 18°C-27°C
Humidity: 40% to 65%, without condensation
Rate of change Temperature: No more than 2°C per hour
Humidity: No more than 5% per hour
Environmental
Storage
environment
Temperature: 4°C to 50°C
Humidity: 40% to 80%, without condensation (When ink has been
discharged.)
To Next Page
