7.3.3. Backup parameter installation procedure
The following is the procedure for installing the backup parameter from the memory card into the new
Mainboard assembly.
Use the following procedure to install backup parameters.
(1) When using a flash memory card
Step 1 : Install the memory card for the backup into the memory card connector slot for the new
Mainboard assembly.
Notes :
¾ Install the memory card so that its front is toward the inside of the printer.
Step 2 : Turn the power to the printer on.
¾ After all of the lamps on the operation panel come on, the LED display on the panel displays
"PRINTER→CARD".
Step 3 : Press either the [MENU ↑] key or [MENU ↓] key on the operation panel.
¾ "CARD→PRINTER" is displayed on the LED display on the operation panel.
Step 4 : Press the [ENTER] key on the operation panel.
¾ The LED display on the operation panel displays "C→P Started".
¾ Backup parameter creation begins.
Step 5 : If the backup parameter has been created correctly, "C→P Completed" is displayed on the
operation panel.
Step 6 : Turn off the power source to the printer.
Step 7 : Remove the memory card for parameter backup.
Step 8 : Reinstall the memory cover
(2) When not using a flash memory card
The settings should be input by the panel.
Input following the procedures below.
Step 1 : Install the firmware according to "Firmware installation".
Step 2 : Follow the instructions in "Machine size select menu" to select the machine size.
Step 3 : Initialize NVRAM according to "Counter Initialization Menu".
Step 4 : Follow the instructions in "Parameter Update Menu" and refer to the printed adjustment variable
to enter following setting value.
¾ Head voltage
¾ Printing position alignment (Bi-D)
¾ CW adjustment
¾ Media feed distance
¾ Mechanical parameter (Top margin, Bottom margin, Side margin, P_REAR sensor position)
¾ Ink parameter (Initial ink charge flag)
¾ Ink ID mask
¾ Serial number
