Spitfire – Maintenance Manual
200
AP-74096, Rev. 1.0, 09/06/05
5.11.3. Heater Test 30 Menu
This menu heats the temperature up to 30°C.
* Test 30 *
Sending to heat system
The display will mention de current temperature. You can follow the heating of the heater elements on the
display up to 30°C.
* Temperature *
A : R30
B1 : R30 B2 : R30 C : R31
D1 : R31 D2 : R31
5.11.4. Heater Test 50 Menu
This menu heats the temperature up to 50°C.
* Test 50 *
Sending to heat system
The display will mention de current temperature. You can follow the heating of the heater elements on the
display up to 30°C.
* Temperature *
A : R50
B1 : R50 B2 : R50 C : R51
D1 : R50 D2 : R50
5.11.5. Heater Test Max Menu
This menu heats the temperature up to maximum temperature.
* Test MAx *
Sending to heat system
The display will mention de current temperature. You can follow the heating of the heater elements on the
display up to 30°C.
* Temperature *
A : R50
B1 : R70 B2 : R70 C : R70
D1 : R50 D2 : R50
