Spitfire – Maintenance Manual
182
AP-74096, Rev. 1.0, 09/06/05
(5) Mechanical parameter
Update the mechanical position parameters. The setup items are as follows.
¾ Top distance
¾ Bottom distance
¾ Side margin
¾ P_REAR sensor position
* Mechparm *
Top Length 0 – 40.0 +
5.0 mm -
* Mechparm *
Bottom 0 – 40.0 +
5.0 mm -
* Mechparm *
Side 0 – 20.0 +
5.0 mm -
* Mechparm *
Rear Sensor 0 – 27.0 +
17.0 mm -
↓ ENTER
* Mechparm *
Update Parameter
↓ ENTER
* Mechparm *
Updating Parameter
