Spitfire – Maintenance Manual
241
AP-74096, Rev. 1.0, 09/06/05
Notes :
1. Please be careful, when replacing the tubings, it is possible to have kinks in the
tubings. Please avoid this by turning the tubing to the left or the right at the
head connection and/or waste tube connection.
2. Also be careful the tubings do not touch or get stuck in the gears.
1 Critical tubings
2 Gears
