Spitfire – Maintenance Manual
25
AP-74096, Rev. 1.0, 09/06/05
7
10
Paper Guide Support the media during printing
It houses the fixer, post-fixer and dryer.
8
Carriage This is a cover to protect the user from the internal components of the unit. This
is opened during following operation :
When cleaning the cleaning wiper.
9
Foot switch This switch is used to control the Unwinder / Winder
11
Daily Maintenance
Cover
Two covers which can be opened easily for daily maintenance.
12
Front winding
system (winder 100)
Motorized roll-up system.
13
Swingbars Adjust the tension of the media.
14
Rear winding
system (unwinder
100)
Motorized roll-off system.
15
Waste bottle To collect the waste fluid.
To Next Page
