Spitfire – Maintenance Manual
274
AP-74096, Rev. 1.0, 09/06/05
(3) Check the
connections of the
connectors.
•Check if the
waste box sensor
connectors are
connected to the
rear side cap R.
• Redo the
connections of the
following
connectors.
• Mainboard : J120
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
(4) The Mainboard
assembly may be
damaged.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
Notes :
¾ The number between brackets [ ] on the error display indicates the cartridge
number.
